Operating System & CPU
Sierra wireless Q2686
OTA Firmware Upgrade*
System Indicators
GPS LED – Blink GPS fix
GPRS LED – Blink GPRS Connected
GPRS System
Sierra wireless Q2686
GPRS Multi-slot Class 10
SIM interface: 3Vdc
TCP-IP/SMS interface
GPS Performance
SirfStar IV
Position Accuracy : 2.5m
Acquisition: 29 S

Operating Conditions
Operating: -10C to 65C
Storage: -2OC to 8OC
Dimensions & Weight
105 (L) x 75 (W) x 23 (H) mm
Aluminum Casing

Communication & Sensor Ports
4-16 optical-isolated Inputs
2-6 Outputs (Open Drain, 300mA /12V)
2 Analog ADC Inputs (0 ~ 12Vdc)
1 External UART Interface
Power
External Power Directly from Vehicle Fuse Box: 9 ~ 30Vdc
Typical Power 100 mA@12V
Battery 3.7V/1200MA, Support 6-12 Hours
Packing List
1 x AVL Box
1 x GPS/GPRS Antenna
1 x Cable Expansion
1XImmobolizer relay
1XPanic Button
1XConfiguration Software /Utils

Integration & Support
Full customized Communication Protocol
TCP /UDP/SMS Supported
